TS2602 Advanced Keyboard
The TrickleStar® Advanced Keyboard is a 105-key USB Type C keyboard featuring radar-sensing technology to detect user absence and automatically put the computer to sleep. It's compatible with PC, Linux, and Mac operating systems, requiring no software installation—just adjust two switches and plug it in for quick setup.
Calculate your savings here: TrickleStar Savings Calculator
TS2602 Advanced Keyboard
The Advanced Keyboard is compatible with PC (Windows and Linux) and Mac computers.
There are also dual markings on the special keys supporting functions unique to PC and Mac computers respectively.
No. The Advanced Keyboard is a plug-and-play device for both PC and Mac computers. You do not need to download and install any drivers at all.
The Keyboard Setup Assistant window is shown when user plugs in a third-party keyboard to the Mac for the first time.
This assistant helps the Mac to identify the keyboard layout and ensures that the character shown matches with the key pressed by the user.
Simply follow the instructions on the window to set up the Advanced Keyboard for use with Mac computers.
FAQs
Find answers to common questions about our Advanced Keyboard to help you get the most out of your experience.
You may use the USB Type-C to USB Type-A adapter (included in the Advanced Keyboard packaging) to connect to your computer.
You may configure the countdown timer by selecting it on the Countdown Timer Switch in the settings compartment.
Options include:
Position “1” – 30 seconds
Position “2” – 3 minutes
Position “3” – 6 minutes
You may select the operating system of the computer accordingly by configuring the Operating System Switch in the settings compartment.
Options include:
“PC” – for Windows and Linux computers
“Mac” – for Mac computers
By default, when the adjustable feet are folded in, the keyboard’s typing angle is 1.5˚ with a maximum keyboard height of 21.2 mm.
When the adjustable feet are folded out, the keyboard’s typing angle increased to 10.7˚ with a maximum keyboard height of 40.2 mm.
Users are advised to try out both configurations and select the one they are most comfortable with to reduce typing fatigue.
Please ensure that the “Operating System” selector switch is configured correctly. Then, unplug the keyboard’s USB connector from your computer and plug it in again.
This is normal behavior, where the computer periodically wakes up to check for emails, schedule updates and other network activities during sleep state (known as “Power Nap” in Macs and “Modern Standby” in Windows 10 computers). However, the display remains turned off the entire time.
During these periods, the keyboard detected the computer waking up to update information, so the LED indicator lights up. Once the computer goes back to standby/sleep state, the LED indicator will also turn off by itself.
